Cub Cadet Ultima ZT 3 60

Cub Cadet Ultima ZT3 60 Zero-Turn Mower with Lap Bar Control

Built for commercial-grade performance, the Ultima ZT3 60 delivers powerful cutting capability, premium comfort, and a wide-area cut — ideal for tackling large properties with speed and precision.

Key Features:

- 24 HP / 725cc Kawasaki® FR730V Twin-Cylinder OHV Engine – Commercial-grade power that meets your yard’s toughest demands
- Commercial-Grade Dual Hydrostatic Transmissions – Quick, effortless ground speeds up to 7.5 MPH forward (3.5 MPH reverse)
- Premium 24-in. High-Back Seat – Automotive-inspired, fully adjustable with cushioned armrests, ball-bearing seat slide, and advanced polymer seat isolators for maximum comfort at top speed
- 60-in. AeroForce Fabricated Deck – Heavy-duty reinforced leading edges deliver a signature cut with fewer clumps and stragglers, finer clippings, and increased evenness

Full Specifications:

Engine

- Brand/Model: Kawasaki® FR Series, 730V
- Displacement: 726cc, Twin cylinder
- Output: 24 HP
- Air Filter: Single element
- Choke: Separate choke
- Fuel Delivery: Carburetor
- Fuel: Non-ethanol gas, 5 gal. US (13.25 L) tank
- Oil: 10W30, 1 qt. US (2 L)
- Charging System: 15 amp regulated
- Governor: Mechanical
- Lubrication: Fully pressurized, with oil filter
- Starter: Electric, Ignition Key start

Cutting Deck

- Width: 60 in., 11-gauge steel, Fabricated construction
- Blades: 3
- Cutting Height Range: 1″ – 4.5″ (15 positions)
- Deck Lift: Foot pedal with dial adjust
- PTO Engagement: Electric
- Anti-Scalping: 3 gauge wheels

Drive System

- Type: Hydrostatic (Tuff Torq® TZ450)
- Forward Speed: 7.5 MPH / 12.0 km/h
- Reverse Speed: 3.5 MPH / 5.6 km/h
- Turning Radius: 0°

Comfort & Controls

- Seat: 24″ high-back, lever adjustable, cushioned armrests, ball-bearing slide, polymer seat isolators
- Steering: Lap bars
- Brakes: Disc
- Parking Brake: Lap bar integrated
- Cup Holder: Yes
- Headlights: Dual-LED

Battery

- 12V AGM, 210 CCA

Chassis & Tires

- Frame: 2″ x 2″ tubular steel with corrosion protection
- Front Tires: 11″ x 6″-5″
- Rear Tires: 20″ x 12″-10″
- Tire Tread: Turf Master / Multi Trac
- Rear Tow Hitch: Yes

Additional Specifications

- Hour Meter: Yes
- Mulch Kit: Available separately
- Operator Presence System: Yes

Model Number: 17AZEAC5A10 Series: Ultima Series™ ZT
