Toro GrandStand 72509 23.5hp Kawasaki FX Engine 60″ FAB Deck Mower

- Conserves space to get more machines on your trailer, or allows for a smaller trailer and lighter load.
- Foldable operator platform instantly converts the machine to a walk-behind.
- Great visibility for easy navigation around obstacles, protecting the operator, mower, and property.
- Quick access to the engine, hydros and controls with the easy removal of the fuel tank.
- No hydraulic hoses, reduced parts, no routine greasing and simplified design to save you time.
- Self-adjusting suspension and a larger platform area for a more secure stance on sloped terrain.
- The TURBO FORCE® cutting deck is built to withstand the long, tough days on the job.
- 10.5 gallon fuel tank for fewer fill-ups. Transparent tank make it easy to gauge the fuel level.
- A wide stance and optimal balance enhance hillside stability and control.
- Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.

Specifications

Adjustable Discharge Baffle Standard, Tools-Free

Air Filter Heavy-Duty Canister Air Cleaner

Anti Scalp Wheels Standard

Blade Tip Speed 18,500 ft/min / 5,638 m/min

Blades 0.204 in. (0.5 cm) heat-treated steel

Box Dimensions 90 in. x 70 in. x 52 in. / 228.6 cm x 117.8 cm x 132.1 cm

CARB Compliant Not CARB Compliant

Carrier Frame 3 in. x 1.5 in. x 12 gauge (7.6 cm x 3.8 cm x 12 gauge)

Caster Tires 11 in. x 4 in. – 5 in. (27.9 cm x 10.2 cm – 12.7 cm) Flat-Free Semi-Pneumatic

Clutch Electromagnetic

Comfort Platform Foldable Operator Platform with Suspension

Controls Twin lever

Deck Design 7-gauge 60″ (152.4 cm) TURBO FORCE® w/bull-nose bumper

Deck Material 7 Gauge Steel

Deck Size 60 in / 152 cm

Discharge Chute Rubber

Drive System Unitized Pumps 10cc rev Wheel Motors 10 cir

Drive Tires 20 in. x 10.5 in. – 8 in. (50.8 cm x 26.7 cm – 20.3 cm)

Engine 23.5 hp* Kawasaki FX730V 726 cc

Engine Brand Kawasaki

Engine Displacement (cc) 726 cc

Engine Horsepower 23.5 hp

Forward Ground/Transport Speed Up to 10.0 mph / 16.0 kph

Front Bumper Reinforced Bull-Nose

Fuel Capacity 10.5 gal. / 39.7 L / 42 Qt.

Fuel Type Gasoline

Height of Cut 1.5 – 5.0 in. / 3.8 – 12.7 cm

Hour Meter Standard

Hydraulic Fluid Premium synthetic

Product Type Stand-On Mowers

Product Use Commercial

Spindle Bearings Maintenance-free

Spindle Housing 9 in / 22.9 cm Diameter Cast Aluminum

Start Type Electric

Steering Controls Twin Lever

Weight 960 lbs / 435.4 kg

Disclaimer

*23.5 HP gross at 3,600 RPM SAE J1940 and SAE J2723, as rated by Kawasaki®. As configured to meet safety, emission and operating requirements, the actual engine horsepower on this mower may be significantly lower.

Accessory List (Not Included)

Model/Part # Description

139-6655 Recycler Mulch Kit
